Hesco Bastion Mil 4 Hesco Bastion Price Weave Mesh Galvanized Hesco Flood Barrier For River Bank
Gabion Hesco Barrier Information:
Flood barrier fence is made of collapsible wire mesh, geotextile, spring wire and other fittings. It can be filled in sand, earth, cement and stone etc, which can be obtained locally material. This new type of gabions can be used for military fortifications, flood barrier, and semi-permanent dike or barrier against small-arms.
Besides, it can be used in separate cell or some cells joint together.
Woven Gabion Box also named gabion box, is weaved by corrosion resistance, high strength and good ductility galvanized wire or PVC coating wire through mechanical. Wire's material is zinc-5% aluminum alloy (galfan), low carbon steel, stainless steel or iron. Gabion mattress is similar to gabion basket. But gabion mattress's height is lower than gabion basket, structure is flat and big. Gabion basket and gabion mattress are stone containers, uniformly partitioned into internal cells, interconnected with other containers and filled with stone at site to form flexible, permeable, monolithic structures to control and guide water or flood, protect dam or seawall, or used as retaining walls, channel lining and other applications.
Gabion Hesco Barrier material:
A. Galvanized steel wire: diameter 2.0MM-4.0MM, tensile strength >380Mpa, zinc :240g / m2.
B. Zinc 5% Aluminum - wire diameter 1.0MM-3.0MM, tensile strength >380Mpa.
C. Coated galvanized steel wire: low carbon steel wire, pvc coated.
| Product Type | welded mesh |
| Material | black wire, galvanized wire |
| Wire Diameter | 4mm, 5mm, 6mm |
| Mesh Size | 76.2*76.2mm,etc |
| Width | 2', 2'6", 3'3", 3'6", 5', 7', etc |
| Length | 10', 4', 18', 32', 30',95' |
| Height | 2', 2'6", 3'3", 3'6", 5', 7', etc |
Application:
Military defensive;
Perimeter security and defense walls;
Defensive firing positions;
Highway checkpoints;
Flood control;
Water courses;
Emergency flood deployment;
Erosion control.
Gabion Hesco Barrier specificaiton:
| Length | Width | Height | Diaphragm | CUM | The tolerance |
| M | M | M | Unit | M3 | |
| 2 | 1 | 0.3 | 1 | 0.6 | |
| 3 | 1 | 0.3 | 2 | 0.9 | |
| 4 | 1 | 0.3 | 3 | 1.2 | length+-3% |
| 2 | 1 | 0.5 | 1 | 1 | width+-5% |
| 3 | 1 | 0.5 | 2 | 1.5 | height+-5% |
| 4 | 1 | 0.5 | 3 | 2 | |
| 1 | 1 | 0.5 | 0 | 1 | Hole size |
| 1.5 | 1 | 1 | 0 | 1.5 | 60x80mm |
| 2 | 1 | 1 | 1 | 2 | 80x100mm |
| 3 | 1 | 1 | 2 | 3 | 100x120mm |
| 4 | 1 | 1 | 3 | 4 | |
Gabion Hesco Barrier featuers:
Economic.
Simple installation.
Weather proof under natural destroy.
Corrosion resistant.
Less transport freight.
Flexibility is good.
Corrosion resistance.
Gabion Hesco Barrier application:
1). Control and guide of water or flood
2). Preventing of rock breaking
3). Rock fall protection
4). Water and soil protection
5). Bridge protection
6). Strengthening structure of soil
7). Protection engineering of seaside area.
8). Port project
9). Keep off dust wall
10.roadway protection.
Gabion Hesco Barrier Package:
1.With plastic weaving bags outside
2.With wooden pallet cloth
3.Less transport freight. It can be folded together for transport and further installation.
